| 1. Server board: | (for KVM-2115S only) | |
| CPU: | NS GX1, 300MHz | |
| Chipset: | Geode CS5530 | |
| DRAM: | One 168 DIMM for PC-133, 256MB max. | |
| VGA Controller: | CS5530 built-in 1.5~4MB share memory | |
| LAN: | RJ-45, Realtek 8139C, 10/100M | |
| IDE: | One IDE connector, ATA 66. | |
| USB : | 2 USB ports | |
| 2. Chassis: | Heavy duty steel | |
| 3. Power supply: | 1U 150W ATX power supply | |
| 4. LCD Panel: | LG XGA 15¡¨TFT, 1024 x 768, 256M color | |
| 5. Keyboard/Trackball: | Cherry English keyboard with trackball | |
| 6. KVM switch: | 8 ports (KVM-2115S, KVM-2115) | |
| 2 ports (KVM-2115U) | ||
| 7. OSD ( On Screen Display): | Supports brightness, resolution, frequency and security setup | |
| 8. Dimensions: | KVM-2115S | (445.5W x 640D x 44H mm) |
| KVM-2115 | (445.5W x 570D x 44H mm) | |
| KVM-2115U | (445.5W x 450D x 44H mm) | |
| 9. Accessories | Dual sliders for KB/Panel | |
